How TechSew Industrial Machines Are Shipped and Packaged
Techsew industrial machine heads are packed in a secured box or crate and will be shipped under the assembled table on a skid or pallet. The customer is responsible for installing the machine head into the table, connecting the motor belt/ belt guard and assembling the thread tree using the included hardware. To receive additional aid, TechSew has a few videos on their YouTube page that can help or call and SMP representative who can assist you through the process.
Disclaimer: Due to the weight of the table with motor, there might be some minor marring or scratches due to shipping. This is normal when shipping industrial machines because of the weight associated with the items. Some machines may be subject to additional freight shipping where the machine is shipped via a crate due to the size and weight. View our freight policy here.
NO RETURNS OR CANCELATION OF ORDERS
All TechSew Machines are made to order. Cancelations of orders must occur within 24 hours of placing the order. Once the order has been received at the Manufactory and production has started no cancelations will be allowed.
Due to the weight, packing and shipping method No Returns will be allowed.
If you have any questions, please call our sales support team: 800-401-8151
Techsew 4800 Cylinder Walking Foot Industrial Sewing Machine
- Compound walking-foot feeding mechanism – Sews up to 1/2″ thick leather
- 10″ Cylinder arm
- Large, extra-capacity bobbin
- Uses thread sizes #46 to #277
- Dual tension control
- Adjustable presser foot climbing mechanism
- Integrated bobbin winder
- Includes assembled table & adjustable speed SmartServo motor
The Techsew 4800 is designed for sewing a broad range of leather goods including bags, belts, wallets, upholstery, saddle bags, satchels and more. It is also suitable for sewing nylon webbing, canvas, denim, heavy fabrics and synthetics.
With its higher presser foot clearance, newly adopted dual-tension control, adjustable presser foot climbing mechanism and larger thread size capability, the 4800 offers increased work efficiency along with the highest seam quality for fine leather products.
APPLICATIONS:
- Light to heavy-weight leather (1-2oz to ½” maximum thickness)
- Light to medium weight nylon webbing
- Medium to heavy weight canvas, denim, fabrics, synthetic materials
Features and Specifications
Features
- Compound walking foot feeding mechanism
- Large extra-capacity hook (M-style bobbin)
- Dual-tension control for more precise thread tension
- Adjustable presser foot climbing mechanism helps maintain consistent stitch length on uneven materials
- Includes variable speed SmartServo motor and speed reducer pulley for stitch by stitch control of sewing speed
- Drop-in bobbin system for easy access to the bobbin
- Reverse feed to reinforce stitches
- Integrated bobbin winder
- Knee lifter to raise the presser foot
- Safety clutch
- Includes Reinforced U-table, motor, tools, LED lamp, instruction manual, accessories
- Limited Lifetime Warranty included
- Individually inspected and sewn-on prior to shipping
Specifications
- Presser foot clearance: 5/8” (16mm)
- Sewing Capacity: ½” (13mm)
- Needle Bar Stroke: 36mm
- Maximum stitch length: 9mm
- Cylinder arm length: 10.5”
- Cylinder arm diameter: 3” (72mm)
- Needles: 135×17 or 135×16 sizes 18 to 24
- Thread: sizes #46 to #277
- Maximum sewing speed: 2500 SPM
- Hook: Large extra-capacity hook
- Motor: 750W 110V variable speed SmartServo
Includes assembled table & adjustable speed servo motor
